T-MOTOR MN3510 KV360 provides up to 1.9 kg of thrust with 330 W max power for 3-6S multi-rotors. The 117 g Navigator-series motor is tuned for stable, efficient aerial photography missions.
* Specifications are provided for reference. Please verify the latest specifications with the manufacturer.
Drone Motors
The T-MOTOR AT2308 KV1450 is a lightweight fixed-wing motor for 320-500 g sailplanes and trainers, delivering 250 W max power at 47 g. Rated for 23 A peak, it offers crisp throttle response for small gliders.
UAV Motors
The T-MOTOR U7 KV280 is a Power-type BLDC motor for professional photography multi-rotors. At 317 g including cables, with a 60.7 x 39.5 mm body and a 6 mm shaft, it runs 3-8S LiPo to 800 W max power and 35 A continuous over 180 s. A 22 x 6.6 in propeller takes it to 4.64 kg of thrust on the manufacturer bench.
Drone Motors
The AT4120 KV250 is a long-shaft BLDC motor for VTOL fixed-wing airframes, 3D models up to 3500 g and sailplanes up to 5000 g. At 304 g with a 50 x 69 mm stator, it runs 12S LiPo to 2100 W max power and 45 A peak, producing up to 6.7 kg of thrust on 16 x 8 propellers.
UAV Motors
The T-MOTOR MN1115 KV130 is a heavy-payload BLDC motor for 60 kg-class multirotors. At 1055 g including cables, with a 120.5 x 47.9 mm body and a 36N40P stator, it runs 12S LiPo to 2816 W max power and 180 A peak. The manufacturer bench table lists up to 33340 g of thrust on a G36 x 11.5 in propeller at 46.1 V.
UAV Motors
T-MOTOR MN4014 KV400 delivers up to 3.3 kg of thrust with 900 W max power for 4-8S platforms. Weighing 171 g, this Navigator motor balances power and endurance for professional aerial photography UAVs.
UAV Motors
The T-MOTOR MN6007 II KV160 is an Antigravity-type BLDC motor for multi-rotor, VTOL and heavy-lift UAVs. At 159 g with a 67.2 x 26.1 mm body, it runs 12S LiPo to 1120 W max power and 23.7 A peak, and delivers up to 6419 g of thrust on a 22 x 6.6 in propeller.
Drone Motors
The AT4130 KV230 Long Axis motor delivers 2500 W max power with 60 A peak current for large multi-rotors and fixed-wing UAVs. Weighing 408 g, its durable 50 mm stator handles sustained heavy loads.
Drone Motors
The T-MOTOR AT2826 KV900 is a long-shaft BLDC motor for fixed-wing airframes. Weighing 175 g with a 35.2 x 69.5 mm body, it runs 3-4S LiPo to 820 W max power and 57 A peak, and produces up to 3409 g of thrust on a 13 x 6.5 in propeller.
UAV Motors
The P80 III KV100 is a 649 g powerhouse for agricultural drones, delivering 2700 W max power with a 36N42P stator. Rated for 60 A peak current, it drives large propellers with stable, efficient output for heavy spray payloads.
UAV Motors
The T-MOTOR MN1320 KV49 is a high-thrust BLDC motor for 100 kg-class multirotors. At 2070 g including cables, with a 150 x 56 mm body and a 36N42P stator, it runs 24S LiPo to 2900 W max power and 150 A peak. The manufacturer bench table lists up to 58958 g of thrust on an NS45 x 17.5 in propeller at 92 V.
UAV Motors
T-MOTOR U15XXL KV29 pushes thrust to 100 kg for manned aircraft propulsion, handling 210 A peak in a 5.1 kg motor. The 36N42P stator and robust bearings target heavy-lift drones and passenger-carrying eVTOL platforms.
Drone Motors
The T-MOTOR V10 KV160 is a VTOL BLDC motor for large multi-rotor airframes. Weighing 865 g with a 106.6 x 48 mm body, it runs 12S LiPo to 7000 W max power and 155 A peak, and produces up to 27976 g of thrust on a G30 x 10.5 in propeller.
BLDC motor for long endurance UAV selection follows one chain: efficiency, heat,···
How to choose UAV propulsion motors: KV, stator configuration, internal resistan···
UAV Motors
The T-MOTOR U13 II KV65 is a Power-type BLDC motor for heavy-lift industrial multi-rotors. At 975 g including cables, with a 100 x 60 mm body and a 15 mm shaft, it runs 22-25S LiPo to 6720 W max power and 68 A peak over 180 s. The manufacturer bench table lists up to 28.7 kg of thrust on a G32 x 11 in propeller.
UAV Motors
The T-MOTOR MN1130 KV45 is a heavy-payload BLDC motor for 100 kg-class industrial multirotors. At 1740 g including cables, with a 120.5 x 65.9 mm body and a 36N40P stator, it runs 24S LiPo to 3218 W max power and 132 A peak over 180 s. The manufacturer bench table lists up to 57306 g of thrust on an NS47 x 18 in propeller at 92 V.
UAV Motors
T-MOTOR P60 Pin KV170 is a high-power multi-rotor motor for agricultural UAVs, producing 1800 W max power at 375 g. Its 24N28P stator and pin-mount design handle large propellers with reliable, efficient thrust.
UAV Motors
The MN4006 KV380 is a compact 68 g aerial photography motor with 380 W max power and 16 A peak current on 4-6S. Its 18N24P stator delivers efficient, quiet thrust for small camera drones.
UAV Motors
The T-MOTOR U10 II KV100 is a U-Efficiency series BLDC motor for industrial multirotor UAVs. Weighing 415 g with a 98.6 x 33.1 mm body, it runs 12S LiPo to 1600 W max power and 32.4 A peak, and produces up to 10600 g of thrust on a G30 x 10.5 in propeller. It is IP45 rated with a 36N42P configuration and an MTBF of about 1000 hours.
UAV Motors
T-MOTOR U15 II KV80 is a heavy-lift powerhouse producing 8580 W max power and up to 36.5 kg of thrust on 12-24S. The 1740 g, 147 mm motor with 36N42P stator serves industrial drones and manned-class multi-rotors.
UAV Motors
The P80 III KV100 is a 649 g powerhouse for agricultural drones, delivering 2700 W max power with a 36N42P stator. Rated for 60 A peak current, it drives large propellers with stable, efficient output for heavy spray payloads.
UAV Motors
The U15XL KV38 delivers up to 81 kg of thrust for manned aircraft and heavy-lift UAVs, with 180 A peak current in a 4.4 kg, 151 mm motor. Its 36N42P stator is built for sustained, reliable output on 24 S buses.
UAV Motors
The T-MOTOR U3 KV700 is a lightweight multi-rotor UAV motor delivering up to 1.8 kg of thrust with 500 W max power at just 128 g. A 12N14P stator and efficient cooling make it popular for industrial and agricultural drones.
UAV Motors
The T-MOTOR U7 KV280 is a Power-type BLDC motor for professional photography multi-rotors. At 317 g including cables, with a 60.7 x 39.5 mm body and a 6 mm shaft, it runs 3-8S LiPo to 800 W max power and 35 A continuous over 180 s. A 22 x 6.6 in propeller takes it to 4.64 kg of thrust on the manufacturer bench.
UAV Motors
The T-MOTOR U11 II KV120 is a Power-type BLDC motor for heavy-lift industrial multi-rotors. At 772 g including cables, with a 79.5 x 51.6 mm body and a 15 mm shaft, it runs 12S LiPo to 2783 W max power and 57.3 A peak over 180 s. The manufacturer bench table lists up to 14.16 kg of thrust on a 28 x 9.2 in propeller at 48 V.
UAV Motors
The T-MOTOR MN3110 KV470 Navigator motor offers up to 1.2 kg of thrust with 330 W max power at only 98 g. Built for 3-6S aerial photography platforms, it combines smooth response with long flight times.
